Victron MultiPlus-II 24/3000/70-32 230V
Internal reference: PMP242305010
Barcode: 8719076048084
Battery voltage
24VDC
Inverter power (VA)
3000
Communication
VE.BUS
VE.CAN
Number of AC inputs
1
Number of AC outputs
2
Inverter model
MultiPlus-II
Continuous output power at 25°C/40°C (W)
2400
Peak power (W)
5500
Three Phase and parallel operation
Ja
Charge Current (A)
70
Dimensions (mm)
499 x 268 x 141
Brand
Victron Energy
Synergrid
Synergrid C10/26
The MultiPlus-II is a multifunctional inverter/charger with two AC outputs. Suitable for professional marine, yachting, vehicle, and land-based off-grid systems, it also provides the isolation and redundancy required for ESS setups. PowerControl allows the MultiPlus-II to prevent grid or generator overload, while PowerAssist boosts AC power during peak demand. In the event of an outage, the inverter switches over in milliseconds, keeping computers and sensitive electronics running without interruption. The battery charger combines speed with efficiency through a smart adaptive algorithm that extends battery life. Ready for expansion, the MultiPlus-II supports parallel and three-phase configurations when a system needs to scale.
Note: for a short period of time this product was called MultiGrid-II.
