Victron Quattro 48/8000/110-100/100 230V VE.Bus
Internal reference: QUA488024000
Barcode: 8719076032953
Brand
Victron Energy
Number of AC inputs
2
Number of AC outputs
2
Battery voltage
48VDC
Dimensions (mm)
470 x 350 x 280
Communication
VE.BUS
VE.CAN
Continuous output power at 25°C/40°C (W)
6400
AC Input voltage
230VAC
Charge Current (A)
110
Inverter model
Quattro
Inverter power (VA)
8000
Three Phase and parallel operation
Ja
Peak power (W)
16000
Synergrid
Synergrid C10/26
Similar to the MultiPlus, the Quattro is also a combined inverter and charger. Additionally it can accept two AC inputs and automatically connect to the active source. Its many features include a true sine wave inverter, adaptive charging, hybrid PowerAssist technology plus multiple system integration features such as three or split phase operation and parallel operation.
