Victron Phoenix Inverter 48/3000 230V VE.Bus
Internal reference: PIN483020000
Barcode: 8719076023852
Battery voltage
48VDC
Inverter power (VA)
3000
Communication
VE.BUS
Model DC-AC inverter
Phoenix Inverter
Continuous output power at 25°C/40°C (W)
2400
Peak power (W)
6000
Three Phase and parallel operation
Ja
Dimensions (mm)
362 x 258 x 218
Brand
Victron Energy
Pure sine wave output, high peak power and high efficiency. Combined high frequency and line frequency technologies ensure the best of both worlds.
SinusMax - Superior engineering
Developed for professional duty, this range of inverters is suitable for the widest range of applications. The design criteria have been to produce a true sine wave inverter with optimised efficiency but without compromise in performance. Employing hybrid HF technology, the result is a top quality product with compact dimensions, light in weight and capable of supplying power, problem free, to any load.
Parallel and 3-phase operation capability
Up to 6 Inverters can operate in parallel to achieve higher power output. Six 24 V 5000 VA units, for example, will provide 24 kW / 30 kVA output power. Operation in 3-phase configuration is also possible.
