Victron MultiPlus-II 48/10000/140-100 230V
Internal reference: PMP483105000
Barcode: 8719076044956
Tension de batterie
48VDC
Puissance onduleur (VA)
10000
Communication
VE.BUS
VE.CAN
Nombre d'entrées AC
1
Nombre de sorties AC
2
Model de convertisseur
MultiPlus-II
Puissance permanente à 25°C/40°C (W)
8000
Puissance de crête (W)
18000
Fonctionnement en mode triphasé et parallèle
Ja
Courant de charge (A)
140
Dimensions (mm)
677 x 363 x 206
Marque
Victron Energy
Synergrid
Synergrid C10/26
The MultiPlus-II combines the functions of the MultiPlus and the MultiGrid.
It has all the features of the MultiPlus, plus an external current transformer option to implement PowerControl and PowerAssist and to optimize self-consumption with external current sensing (max. 32A).
It also has all the features of the MultiGrid with built-in anti-islanding and an increasingly long list of country approvals.
Note: for a short period of time this product was called MultiGrid-II.
