Victron Quattro 48/10000/140-100/100 230V VE.Bus
Internal reference: QUA481030010
Barcode: 8719076024200
Battery voltage
48VDC
Inverter power (VA)
10000
Communication
VE.BUS
VE.CAN
Number of AC inputs
2
Number of AC outputs
2
Inverter model
Quattro
Continuous output power at 25°C/40°C (W)
8000
Peak power (W)
0
Three Phase and parallel operation
Ja
Charge Current (A)
140
Dimensions (mm)
470 x 350 x 280
Brand
Victron Energy
Synergrid
Synergrid C10/26
Similar to the MultiPlus, the Quattro is also a combined inverter and charger. Additionally it can accept two AC inputs and automatically connect to the active source. Its many features include a true sine wave inverter, adaptive charging, hybrid PowerAssist technology plus multiple system integration features such as three or split phase operation and parallel operation.
