Victron Quattro-II 48/5000/70-50/50 230V
Internal reference: QUA482504010
Barcode: 8719076054092
Battery voltage
48VDC
Inverter power (VA)
5000
Communication
VE.BUS
VE.CAN
Number of AC inputs
2
Number of AC outputs
2
Inverter model
Quattro-II
Continuous output power at 25°C/40°C (W)
4000
Peak power (W)
9000
Three Phase and parallel operation
Ja
Charge Current (A)
70
Dimensions (mm)
565 x 320 x 148
Brand
Victron Energy
Synergrid
Synergrid C10/26
Similar to the MultiPlus-II, the Quattro-II is also a combined inverter and charger. Additionally it can accept two AC inputs and automatically connect to the active source. Its many features include a true sine wave inverter, adaptive charging, hybrid PowerAssist technology plus multiple system integration features such as three or split phase operation and parallel operation.
