Victron Skylla-TG 24/80(1+1) 230V
Internal reference: SDTG2400801
Barcode: 8719076025771
Battery voltage
24VDC
Charge Current (A)
80
Number of DC outputs
1+1
Protection
IP21
Communication
AC Input voltage
230V
Battery charger model
Skylla-TG
Dimensions (mm)
365 x 250 x 257
Brand
Victron Energy
One full rated output and one 4 Amp output. Charge voltage can be precisely adjusted to suit any battery system. The input for the charger is 230V at 50/60HZ. Charge voltage can be measured directly on the battery terminals in order to compensate for voltage loss due to cable resistance. An external sensor allows measuring battery temperature and compensating charge voltage accordingly.
